SKU: 14037
Part Number: RPi Camera (M)
Brand: Waveshare
wiki:
www.waveshare.com/wiki/RPi_Camera_(M) Raspberry Pi Camera Module, Fisheye Lens, Wider Field of View
Uz ovu kameru dobijate flet kabl za povezivanje sa raspberry Pi (2, 3, 4) pločama. Bele je boje.
Features
- Raspberry Pi Camera, supports all revisions of the Pi
- Fisheye Lens, offers wider field of view
- 5 megapixel OV5647 sensor
- Adjustable focus distance
- Camera specifications
- CCD size : 1/4inch
- Focal Length : 0.87mm
- Angle of View (diagonal) : 200 degree (while other normal cameras are typically 72 degree)
- Sensor best resolution : 1080p
- 4 screw holes
- Used for attachment
- Provides 3.3V power output
- Supports connecting fill flash LED
- 2592 × 1944 still picture resolution
- Support 1080p30, 720p60 and 640x480p60/90 video record
- Dimension: 25mm x 24mm
Note: to use the camera with Raspberry Pi Zero / Zero W / Zero WH, you need to buy a specific cable: Raspberry Pi Zero v1.3 Camera Cable
Link Waveshare wiki
PACKAGE CONTENT
Weight: 0.017 kg
The included FFC is 16cm, if you need a longer cable, please consider: RPi Camera Cable 60cm
- RPi Camera (M) x1
- 15-pin FFC (opposite sides contact) x1
