>Uz ovu kameru dobijate flet kabl za povezivanje sa raspberry Pi (2, 3, 4) pločama. Bele je boje.
Features
Raspberry Pi Camera, supports all revisions of the Pi
Embedded removable IR-CUT filter, eliminating color distortion in the daylight
Comes with infrared LED, supports night vision
5 megapixel OV5647 sensor
Adjustable focus distance
Camera specifications
CCD size : 1/4inch
Aperture (F) : 1.2
Focal Length : 8mm
Angle of View (diagonal) : 40 degree
Sensor best resolution : 1080p
4 screw holes
Used for attachment
Provides 3.3V power output
Supports connecting infrared LED and/or fill flash LED
Dimension: 31mm x32mm
Note: to use the camera with Raspberry Pi Zero / Zero W / Zero WH / 5, you need to buy a specific cable: Raspberry Pi Zero v1.3 Camera Cable
Note: the actual image pixels is 5MP, which depends on the sensor, so it doesn't matter that there is a 3MP silk mark on the camera.
Link Waveshare wiki
PACKAGE CONTENT
Weight: 0.053 kg
The included FFC is 16cm, if you need a longer cable, please consider: RPi Camera Cable 60cm
- RPi IR-CUT Camera (B) x1
- Infrared LED Board (B) x2
- 15-pin FFC (opposite sides contact) x1
