SKU: 24761
Part Name: 15.6inch QLED Monitor (EU)
Brand: Waveshare
Wiki: http://www.waveshare.com/wiki/15.6inch_QLED_Monitor 15.6inch QLED Monitor
15.6inch QLED Quantum Dot Display, 1920×1080, Optical Bonding Toughened Glass Panel, 100%SRGB, Metal Case, Thin And Light Design
Posetite
Wiki zbog pomoći oko načina povezivanja, instalacije, primera i drugih korisnih informacija pre kupovine. Možete nas i konsultovati na email
office@malina314.com
Size |
Resolution |
Display Port |
Display Panel |
Viewing Angle |
 |
 |
 |
 |
 |
15.6" |
1920×1080 |
mini HDMI |
QLED |
178° |
Touch Type |
Touch Points |
Touch Port |
Touch Panel |
OSD Menu |
 |
 |
 |
 |
 |
Capacitive |
10-Points |
USB-C |
Toughened Glass |
Brightness Contrast |
Sound |
Audio Output |
Enclosure |
Touch Panel Tech |
Gaming |
 |
 |
 |
 |
 |
Hi-Fi Speaker |
3.5 mm Jack |
Metal Alloy CNC |
Optical Bonding |
Xbox360, PS4, Switch |
█ Device & System Support
Raspberry Pi
- Supports Raspberry Pi OS, 10-point touch, driver free
- Supports Ubuntu / Kali / WIN10 IoT, single point touch, driver free
- Supports Retropie, driver free
- Supports all versions of Raspberry Pi
Jetson Nano
- Supports Ubuntu, single point touch, driver free
Vision Five 2
- Supports Debian, single point touch, driver free
PC
- Supports Windows 11 / 10 / 8.1 / 8 / 7, 10-point touch, driver free
Game Console
█ Connection Examples
Working With Raspberry Pi 4B
Working With Raspberry Pi 3B+
Working With Raspberry Pi Zero 2 W
You need to prepare additional mini HDMI adapter and USB cable
Working With Jetson Nano
Working With PC
- for reference only, the above controller boards or hosts are NOT included
█ Display
IPS Display Panel
Excellent Display Performance With 178° Wide Viewing Angle
QLED Quantum Dot Technology
Wider Color Gamut With 100% NTSC, 100% SRGB, 99% Adobe RGB And 97% DCI-P3 Color Gamut Coverage Brighter, Clearer And More Natural Color
More Pure Chroma
Chroma Of QLED Increases 58.3%, Makes The Color More Pure, More Vivid
Longer Lifetime
Due To Its Inorganic Characteristic, The Color Life Of QLED Could Be Up To 60000 Hours Without Color Degradation
Thin And Light Body, Exquisite Craftsmanship
Rounded Edge Design, Comfortable Handheld Experience, With Exquisite Details
Capacitive 10-Point Touch
- up to 10-point touch, depending on the operating system
- up to 6H hardness toughened glass panel
- Optical Bonding, display well and dustproof
Enjoy Gaming
Dual-Track Speaker
Ferrite Hi-Fi Speaker, Larger Volume, Wider Sound Range, Better Sound Quality
█ Interface Introduction
█ Product Show
█ Dimensions (mm)
█ Resources & Services
█ Product Certification
HDMI Certified
-
█ Package Content
- 15.6inch QLED Monitor ×1
- Mini HDMI to HDMI cable ~1m ×1
- USB Type-A to Type-C cable ~1m ×1
- HDMI to Micro HDMI adapter ~1m ×1
- Triangular stand ×1
- OPTIONS 12V 1A Power supply ×1
Weight: 1.745 kg
