USB TO 4CH Serial Converter

Šifra: w25790

3.499,00 RSD

Cena sa PDV

Lista želja ?

Unesi količinu Samo 3 na stanju

Dodaj u korpu

Kategorija: industrijski konverteri
Težina po komadu: 0.233 Kg

odes or more； 422 mode: up to 256 nodes, it is recommended to use repeaters for 16 nodes or more)

Baud rate
300bps ~ 921600bps

PORT D (RS232/485 CHOOSE ONE)
ISOLATED RS232
Connector
Screw terminal

Protection
TVS diode, surge protection & ESD protection, power isolation and signal isolation

Transmission mode
Point-to-point

Baud rate
300bps ~ 921600bps

ISOLATED RS485
Connector
Screw terminal

Direction control
Hardware automatic control

Protection
TVS diode, surge protection & ESD protection, power isolation and signal isolation

Resistor
Onboard reserved 120R matching resistor, NC by default, enabled via jumper

Transmission mode
Point-to-multipoints (485 mode up to 32 nodes, it is recommended to use repeaters for 16 nodes or more)

Baud rate
300bps ~ 921600bps

INDICATORS
PWR
Red power indicator, light up when there is USB connection and voltage is detected

TXD
Green TX indicator, light up when the USB port sends data

RXD
Blue RX indicator, light up when the device ports send data back

OPERATING SYSTEM
Mac, Linux, Android, Windows 11 / 10 / 8.1 / 8 / 7

Basic Function

Supports USB To 4-Ch Multi-Functional Serial Port, Convenient For Expanding Or Debugging Various Industrial Serial Port Devices; Supports USB To 1-Ch TTL + 1-Ch TTL/RS485 + 1-Ch Isolated RS485/422 + 1-Ch Isolated RS232/485

Original Industrial Grade Chip

Onboard Original FT232RNL Chip,
Fast Communication, Stable & Reliable, Better Compatibility

Safer Isolated Design

Onboard unibody power supply isolation, provides stable isolated voltage, needs no extra power supply for the isolated terminal

Onboard unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, low power consumption

Multiple Protection, Safe And Stable

Onboard TVS (Transient Voltage Suppressor), effectively suppress surge voltage and transient spike voltage in the circuit, lightningproof & ESD protection. Onboard self-recovery fuse and protection diodes, ensures the current/voltage stable outputs, provides over-current/over-voltage proof, improves shock proof performance.
