SKU: 22440
Part Number: IMX462-127 2MP Starlight Camera
Brand: Waveshare
Korisne informacije:
www.waveshare.com/wiki/IMX462_2MP_Starlight_Camera IMX462-127 IR-CUT Camera, Starlight Camera Sensor, Onboard ISP, Fixed-Focus, 2MP
IMX462 Starlight Camera 2MP | IR-CUT | ISP
Compatible with Raspberry Pi series boards and Jetson Nano
Device Support
Raspberry Pi series
Supports 4B / 3B+ / 3A+ / Zero / Zero 2 W,
and CM3/3+/4 (extra adapter board required)
Jetson Nano
Supports Jetson Nano developer kit
Specifications
SENSOR |
IMX462-127 |
|
CMOS SIZE |
1/2.8 inch |
PIXELS |
2MP (1920 × 1080) |
CAMERA TYPE |
Color |
FOCUSING |
Fixed focus |
SHUTTER |
Rolling Shutter |
APERTURE |
F1.61 |
|
FOCAL LENGTH |
3.18mm |
|
FIELD OF VIEW |
127.9° |
|
DISTORTION |
< -51% |
|
Starlight Camera Clear Imaging Even In Low Light Conditions
Built-In IR-CUT Correct Color Deviation Of Infrared Camera During The Daytime, Better Imaging Effect
Onboard ISP Integrated Image Signal Processing Circuit, Clearer Imaging Effect
Working With Raspberry Pi directly connect to Raspberry Pi different variants including 5/4B/3B+/3A+/3B/2B/B+/A+,
extra FPC cable is required for Zero / Zero 2 W series
- for reference only, Raspberry Pi 4B and 2W are NOT included.
- Specific driver is required for Raspberry Pi to use the IMX462 camera.
Working With Jetson Nano Direct Connect To Jetson Nano Developer Kit
for reference only, Jetson Nano Developer Kit is NOT included. Outline Dimensions
- PACKAGE CONTENT
Weight: 0.035 kg
IMX462-127 2MP Starlight Camera x1
